Sliding insulated system SMARTIA BM-350S
Description
BM-350S is a modern & flexible insulated sliding system with a modern flat design. It is ideal for refurbishments or renovations thanks to its construction easiness.
Advantages
Excellent value for money
Fairly high energy efficiency
Special solutions for hotels
Competitive manufacturing costs due to reduced fabrication time
Numerous alternative solutions
Good sound insulation
Sensible natural lighting enhancement thanks to the design of the system
High quality frame with certified performance
Generic
| WINDOWS TYPES | THERMAL INSULATION | EXTERIOR SHAPES |
|---|---|---|
| Sliding | Yes | Curved, Flat |
Technical Characteristics
| SASH DEPTH | SASH WEIGHT | MINIMUM VISIBLE ALUMINIUM FACE HEIGHT | MINIMUM VISIBLE ALUMINIUM FACE WIDTH AT THE CENTRAL VERTICAL COLUMN (ADJOINING PROFILE) | MINIMUM VISIBLE ALUMINIUM FACE WIDTH AT THE CENTRAL VERTICAL COLUMN (INTERLOCKING PROFILE) | GLAZING TYPE | MAXIMUM GLAZING THICKNESS | MECHANISM | SEALING METHOD | TYPE OF THERMAL INSULATION |
|---|---|---|---|---|---|---|---|---|---|
| 35 mm | up to 180 Kg | 107 mm | 102 mm | 25 mm | Double | up to 28 mm | Perimetrical locking mechanism | Continuous perimetrical tri fin in two levels brush | Polyamides 24 mm, PVC parts |
Performance
| UF | WATER TIGHTNESS | AIR PERMEABILITY | WIND LOAD RESISTANCE | SOUND REDUCTION |
|---|---|---|---|---|
| from 2,9 up to 4,8 W/m²K | CLASS 6Α | CLASS 3 | C2/B3 | 28 dB |
Characteristics
| TYPES OF TYPOLOGY |
|---|
| Horizontal sliding, meeting stile, Pocket sliding |
TYPOLOGIES
Double horizontal sliding sash
Triple horizontal sliding sash
Four horizontal sliding sashes with meeting stile
Double horizontal parallel sliding window with fly-screen
Quadruple horizontal parallel sliding with meeting stile & fly-screen
Double horizontal parallel sliding window with fly-screen & rolling shutter
Horizontal sliding pocket sash with shutter
Single horizontal sliding pocket sash with fly-screen and shutter
Double pocket horizontal sliding window with fly-screen & shutter
Single horizontal sliding pocket sash with fly-screen and rolling shutter
Double horizontal parallel sliding window with fixed fanlight
Single sliding sash with fixed light
